Basisausstattung
|
|
Komfort Paket
- Änderungen gegenüber der Basisausstattung |
|
Premium Paket
- Änderungen gegenüber der Basisausstattung |
| ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- |
Rahmen:
|
AUFWIND 28" Aluminium
verschiebbares Ausfallende, tapered,
innenverlegte Leitungen |
|
|
|
|
| ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- |
Gabel:
|
SR Suntour SF18 NRX-E Air
63mm Federweg, 15mm Steckachse, tapered |
|
|
|
|
| ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- |
Steuersatz:
|
Acros AZX-203 ZS44 & ZS56
tapered
|
|
|
|
Acros AZ-44 BL & AZ-56
Edelstahlkugellager, tapered,
integrierter Lenkeranschlag |
| ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- |
Motor:
|
Shimano STEPS E6100
250 Watt & 25km/h |
|
|
|
|
| ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- |
Akku:
|
Shimano STEPS E8010
504Wh / 36V / 14Ah / Li-Ion |
|
|
|
|
| ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- |
Laufräder:
|
Shimano Deore Vorderradnabe
Shimano Nexus 5 E Getriebenabe
DT Swiss 545d 28" Felgen
verstärkte Sapim Speichen |
|
|
|
Shimano XT Vorderradnabe
Shimano Nexus 5 E Getriebenabe
DT Swiss 545d 28" Felgen
verstärkte Sapim Speichen |
| ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- |
Bereifung:
|
Continental Contact Plus 28x1,6" (42-622)
Continental Tour Schlauch |
|
Schwalbe Marathon Supreme EVO 28x1,6" (42-622)
Schwalbe Tour Schlauch |
|
Schwalbe Marathon Supreme EVO 28x1,6" (42-622)
Schwalbe Tour Schlauch |
| ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- |
Schaltung:
|
Shimano Nexus 5 E Nabenschaltung SG-C7000
263% Übersetzungsbandbreite
spezielle Abstufung für Pedelecs |
|
|
|
Shimano Nexus 5 E Nabenschaltung SG-C7050 Di2
263% Übersetzungsbandbreite
spezielle Abstufung für Pedelecs |
| ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- |
Schalthebel:
|
Shimano Nexus 5 SL-C7000
mechanischer Schalt-Drehgriff
|
|
|
|
Shimano SW-E6010 Schalter
elektrischer Schalthebel mit + / - Taste sowie
Wahltaste Manuel & Autoamatik-Modus |
| ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- |
Antrieb:
|
Shimano Nexus CN-NX10 Kette
38 x 30 Zähne Kettenblätter |
|
Gates Carbon Drive Zahnriemen
39 x 32 Zähne Riemenscheiben |
|
Gates Carbon Drive Zahnriemen
39 x 28 Zähne Riemenscheiben |
| ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- |
Bremsen:
|
Shimano Deore T6000 Trekking
SM-RT54 Bremsscheiben 180/160mm |
|
|
|
Shimano Deore XT T8000 Trekking IceTec
SM-RT70 Bremsscheiben 180/160mm |
| ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- |
| Lenker: |
Ergotec Climber 40mm Höhe, 39°, 620mm Breite |
|
|
|
|
| ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- |
| Vorbau: |
Ergotec Octopus 50 Ahead 110mm winkelverstellbar |
|
Ergotec Swell-R 70 Ahead 110mm winkelversetellbar |
|
Ergotec Swell-R 70 Ahead 110mm winkelversetellbar |
| ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- |
| Sattelstütze: |
Ergotec Viper 30,9x400mm 10mm Offset |
|
|
|
|
| ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- |
| Sattel: |
Sportourer FLX Gel Flow |
|
|
|
|
| ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- |
| Griffe: |
M-WAVE Cloud Ergo Fix * |
|
Ergon GP1 * |
|
Ergon GP1 * |
| ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- |
| Gepäckträger: |
Racktime Shine Evo Light-It * |
|
|
|
|
| ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- |
| Schutzblech: |
Curana C-Lite 45mm |
|
|
|
|
| ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- |
Beleuchtung:
|
Büchel Shiny 80 LED 80 Lux *
Busch & Müller Rücklicht im Gepäckträger integriert |
|
Busch & Müller IQ-XS E-Bike *
Busch & Müller Rücklicht im Gepäckträger integriert |
|
Busch & Müller IQ-XS E-Bike *
Busch & Müller Rücklicht im Gepäckträger integriert |
| ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- |
| Ständer: |
Hebie Fix 18 |
|
|
|
|
| ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- |
| Gewicht: |
22,80kg garantiert +/- 200g Gr. M |
|
22,4kg garantiert +/- 200g Gr. M |
|
22,2kg garantiert +/- 200g Gr. M |
| ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- |
|
|
|
|
|
|
